Case:
Supermicro SC942I 19"" 4U rackmountable tower case black
free bays: 8x5,25"",1x3,5""
slots: 7x PCI full length
cooling: 3x 120mm & 1x 120mm 3200rpm cooler (FAN-0053 & FAN-0054)
Netzteil: 760W 2+1 redundant / 24/8/4-PIN 12""x13"" / E-ATX
Connectors: rear - 1x VGA / 2x USB / 2x NIC / 1x SCSI / 1x maus / 1x keyboard, front - 2x USB
Frontpanel 2 x eSATA, 3xUSB

Mainboard
Supermicro X7DBE 2xXeonQC 5000P 1333MHz 32GB FBDIMM SATA 3PE 3P 2GL VGA
Prozessor: Dual Intel® Xeon® 5300 Quad-Core (Clovertown) w. 2x4MB L2 Cache bis 2.66 GHz, Intel® Xeon® 5100/5000 Dual-Core (Woodcrest) mit 4MB L2 Cache bis 3.00 GHz / Dual LGA771
Chipsatz: Intel® 5000P
Front Side Bus: 1333 / 1066 / 667 MHz
RAM: 32GB PC667/533 FBDIMM ECC
Slots: 2x PCI-Express(x8), 1x PCI-Express(x4), 2x 64-bit/133-MHz PCI-X (3.3V),  1x 64-bit 100MHz PCI-X (3.3V)
SATA: 6x SATA II Intel® ESB2, SW-RAID 0,1,5,10
Single Ultra DMA (ATA/100)
LAN: 2x 10/100/1000Mbit Base-T Netzwerk Intel® 82563EB
IPMI: Option (IPMI 2.0 mit SuperDoctor III / AOC-SIMLP)
Grafik: ATI® ES1000 SVGA 16MB Video on board
I/O Ports: 2x Seriell / 1x Parallel / 5x USB 2.0
Form Faktor: EATX (305mm x 332mm)
Operating Systems: Microsoft® Windows® 2000 Server, Microsoft, Windows Server® 2003, Microsoft Windows XP, Red Hat®Linux®, SuSE®Linux"

CPUs
2 x XEON® QC 2.33GHz S771 2x6MB L2 1333MHz FSB LGA 45nm Box

RAM
2 x 4GB 667MHz DDR2 ECC Fully Buffered CL5 DIMM Dual Rank, x4

Host Bus Adapters
8K SAS SFF-8088 ext. HBA x8 PCIe RTL SGL

LAN Adapter
Pro/1000 MF Dual Port - PRO/1000 MF Dual Port Server Adapter, 64-bit PCI-X bus, max 133 MHz

HDD
1 x Barracuda ES.2 500GB 32MB System in RAID 1
OpticaDrive/Floppy
DVD-RW Drive SATA

Forensic Componets
2 x Tableau Hardware Write-Blocker (incl. interface and power cabel)
- IDE Drive Write Blocker - SATA Drive Write Blocker - SCSI Drive WB
- IDE Adapter 3,5" to 1,8"
- IDE Adapter 3,5" to 2,5"
- IDE Adapter 3,5" to Zif
- SCSI Adapter 68pol to SCA - SCSI adapter 68pol to 50pol
2 x T35i , Tableau Hardware Write-Blocker (incl. interface and power cabel)
- IDE Drive Write Blocker - SATA Drive Write Blocker
- IDE Adapter 3,5" to 1,8"
- IDE Adapter 3,5" to 2,5"
- IDE Adapter 3,5" to Zif
Forensic CardReader USB extern
2 x T35es Bundle Kit exteranl IDE/SATA Adapter mit eSATA Host Connection

FireWire Cards
2 x PCI-Express FireWire 1394B Karte, 3+1 Ports
2 x PCI-X FireWire 1394B Karte, 2+1 Ports

Display
LCD17 Single Rack-Konsole - EU - 1U LCD17 Rack - Out-of-Band access to the server PS/2 (UK-keyboard)

Remote Access
AOC-SIMLP-B(+)  IPMI 2.0 technology to provide remote access, monitoring and administration for Supermicro server platforms

Software
Windows XP Pro 64-bit, Linux 2.6x
- AccessData FTK-Imager
- EnCase Linen - Air-Imager - GParted


48 months Warranty



9 Terabyte Analyze-Lan-Server



9 Terabyte Analyze-Lan-Server
Double Server Case 15x 5 1/4" 5x 92mm cooler (4x hot swappable in quick-out rack) 710mm x 410mm x 470mm
MX3-5750P 750W Tripple redundant Power Supply
FireWire 800, 4 x USB 2.0 Front
Motherboard: Supermicro X7DBE+
1. Quad & Dual Core Intel® 64-bit Xeon® Support, 667 / 1066 / 1333MHz FSB
2. Intel® 5000P (Blackford) Chipset
3. Up to 64GB DDR2 667 & 533 SDRAM Fully Buffered DIMM (FB-DIMM)
4. Intel® (ESB2/Gilgal) 82563EB Dual-port Gigabit Ethernet Controller
5. 6x SATA 3.0Gbps Ports via ESB2 ControllerSATA Controller
6. 2 (x8) & 1 (x4) PCI-Express, 2x 64-bit 133MHz PCI-X, 1x 64-bit 100MHz PCI-X
7. ATI ES1000 Graphics with 16MB video memory
8. SIMLP IPMI 2.0"
CPU: 2x Xeon E5345 2.33GHZ FSB1333 - Socket: 771/ Cache: 2x4096 KB/ Taktfrequenz: 2,33 GHz/ FSB: 1333 MHz
RAM: 2 x DDR2 4GB PC667 ECC CL5 FULLY - Kapazität: 4096 MB/ PC667 MHz/ ECC-Chip, DDR2 2X2048MB KIT OF TWO
HDD Controller:
3Ware PCI-X 12port SATA RAID Level 0,1,5,10, HotSwap, HotSpare
Adaptec SCSI- Controller 29320 PCI-x
Hard drives:
1x Barracuda ES.2 500GB SATA-II - S-ATA 2 / Cache: 32MB
12x Barracuda ES.2 750GB SATA-II - S-ATA 2 / Cache: 32 MB
3x MB-454SPF 4 x SATA BACKPLANE
Forensic components:
Tableau UltraBay Hardware Write-Blocker (incl. interface and power cabel)
- IDE Drive Write Blocker - SATA Drive Write Blocker - SCSI Drive WB
- IDE Adapter 3,5" to 1,8"
- IDE Adapter 3,5" to 2,5"
- IDE Adapter 3,5" to Zif
- SCSI Adapter 68pol to SCA
- SCSI Adapter 68pol to 50pol

Forensic CardReader USB external
Drives:

SlimLine DVD Writer DL

USB Floppy 1,44MB external drive
In/Output:
Keyboard /Mouse
Operating System:
Windows Server 2003 64-bit 5 CALs /- SuSE Linux 10.3 or higher
Software:
- X-Ways Forensics DEMO
- AccessData FTK-Imager
- EnCase Linen - Air-Imager
- GParted

AntAnalyzer (Forensic Workstation)



Computer Case, Big Tower, CoolerMaster Cosmos 1000
Connector USB FireWire 1x 1394b + 4 x USB 2.0 HUB, 1x eSATA
(for Front Bay)
3 x hard drive cooler 90 mm, 2 x case cooler 120 mm
CE/ATX, 700 Watt BeQuite SLI, aktiv PFC, S-ATA, 24pin

MB: P5E WS Pro S775 X38 ATX - S775, Intel X38 / ICH9R chipset, FSB: 1600/1333 /1066 / 800 MHz, 4 x DIMM, max. 8GB, DDR2 1200(O.C.)/1066/800/667 MHz,
2 x PCIe 2.0 x16, 1 x PCIe x 1, 1 x PCI-X, 2 x PCI,
2 x Gb LAN Southbridge
-6 x SATA 3.0 Gb/s ports - Intel Matrix Storage Technology supports RAID 0, 1, 5 and 10 Ext PATA and SATA controller - 1 x ATA -
2 x External SATA 150/300 (RAID 0,1,10,5)
2 x SATA 150/300 (RAID 0,1,10,5)

CPU: CORE 2 EXTREME QX9650 3.00GHZ - SKT775 FSB1333 12MB CACHE BOXED INYorkfield Core 0,45nm Quad-Core
RAM: 2 x DDR2 4096MB PC800 - PC800 MHz/ NO ECC-Chip, DDR2 (Kit of 2 x 2048MB)

GK: GF 9800GX2 1GB DDR3 - PCIe x16/ NVIDIA/ GeForce 9800GX2/ 1024 MB/ DDR3/ 512 Bit/ HDMI-Out, 2x DVI/ Features: nView, Vista Ready, SLI, OpenGL, HD Ready, DirectX10

Hard drives:
3 x internal BARRACUDA ES 500GB SATA-II Cache: 16 MB
3 x BARRACUDA ES 500GB SATA-II Cache: 16 MB in MB-453SPF SATA 3x SATA Backplane
DVD writer - SlimLine , black

Writeblocker: Ultrabay Tableau T345 with Interface cable,2,5", 1,8", ZIF IDE adapter, 1x HDD cooler external, SCSI Adapters - SCA to 68pol, 50pol to 68 pol.
TK8 Tableau USB KIt external WP Bridge Tableau Carted reader for T8
Floppy 1,44 internal
2 x PCI-EX EX-16410 Firewire 800 4 port

SCSI Controller 29320A-R intern: 1x 50 pol 2 x 68 pol
external:
1 x 68 pol.
Keyboard/Mouse Kit PS2/USB
Windows XP 64-bit or 32-bit




All of our Device have 36 months of guaranty - up to 60 months is optional





Maximal Performance & Quality: TreCorder®



The TreCorder® is the highest performing Device in the world for the mobile digital-evidence-saving in the Computerforensic.

The TreCorder® was developed on demand and together with different public establishments from our home country and foreign countrys

The TreCorder® is equipped with three internal HDD-Writeblocking-Devices (UltraBays), which guarantee a safe and Court-suitable Copy / Cloning without Changing the data.


In the practical test the TreCorder® reaches the following parameters:

The TreCorder copies up to 19,6 GB per minute =
1,17 TB per hour




- made in Germany -


Testreport of the Magazine iX (Issue 01/2008) german language


 ______________________________________________



Three Terabyte in the Forensic PORTABLE-PC OneCorder

- Standard Intel Dual Xeon/Opteron Board or Single CPU

- up to 16 GB ECC/ or 4GB NON-ECC DDR Ram

- up to 4 x 750 GB 7200RPM IDE HDDs for Datas in clip-on frames

- max 500GB 7200RPM IDE HDDs interior

- Write-blocked IDE & SATA & SCSI Connection for Data Acquisition Tableau´s T345

- DVD/CDRW Drive

Special-productions and Small series . . .

Mobile Saving of Digital Evidence = fast and authentic saving of Datas locally,fast and authentic analyzing in our Laboratory, interpretating and archiving.
